Introduction

In this technical review, we evaluate the performance of Murata Electronics' GRM155R71H104KE14D capacitor, a ceramic 100n ±10% 50V X7R surface mount component. As an essential unit in electronics, capacitors are critical for storing electrical charge, releasing, and blocking DC while allowing AC to pass through. Our review provides a comprehensive analysis to help engineers assess this capacitor's applicability for their circuits. The performance will be compared against the statistical benchmark data obtained from other components of the same value.

The GRM155R71H104KE14D's performance will be assessed in terms of Capacitance, Series Resistance, Dissipation Factor, and Quality Factor. The measurements are taken at low voltage (1V) and high voltage (10V) with various test frequencies. We will compare these measurements against the data obtained from other capacitors with similar specifications.

• Pros:
• Wide range of test frequencies from 5kHz to 1MHz
• Comprehensive performance data for multiple parameters
• Capacitance values remain fairly consistent across frequencies
• Capacitance values show modest impact of applied voltage
• Low dissipation factor at most test points
• Cons:
• Quality factor varies marginally across test frequencies
• Limited high-frequency data for higher voltage testing

Overall, this Ceramic X7R capacitor shows promising results. However, a deeper exploration of its vital parameters is required to make a conclusive judgement. Continue reading to find out how the GRM155R71H104KE14D capacitor measures up against the competition in various aspects and its relevance for your specific applications.

Impedance

Upon examining LCR measurements conducted at 1 Volt, it is clear that the GRM155R71H104KE14D capacitor's impedance performance aligns quite closely with the average values of its statistical benchmark. For clarification, LCR measurements are an essential step in analyzing components' characteristics, specifically inductance (L), capacitance (C), and resistance (R), at various test frequencies. At test frequencies of 5 Hz and 10 Hz, the GRM155R71H104KE14D capacitor records impedance values of 311.9k Ohms and 156.3k Ohms, which are remarkably similar to the statistical benchmark's average values of 313.4k Ohms at 5 Hz and 157.2k Ohms at 10 Hz.

Maintaining its outstanding performance, the GRM155R71H104KE14D capacitor continues to exhibit near-optimal impedance figures at higher test frequencies. The capacitor's impedance values at 50 Hz, 100 Hz, and 500 Hz are 31.45k Ohms, 15.77k Ohms, and 3.176k Ohms, respectively. These values consistently match or closely approach the average benchmark values of 31.67k, 15.9k, and 3.207k Ohms for the same frequency points.

This impressive ceramic X7R capacitor from Murata sustains its superior performance at even higher frequency points in the 1 Volt testing range, including 1 kHz, 5 kHz, 10 kHz, and 20 kHz. In these tests, the capacitor either matches or surpasses its benchmark crossover, fulfilling its role as a top-of-the-line component.

Remarkably, the capacitor's excellence does not wane even under higher voltage conditions of 10 Volts. The GRM155R71H104KE14D capacitor continues to outperform its peers across the 50 Hz to 100 kHz range, often yielding impedance values just below the benchmark averages. This incredible consistency signifies a well-engineered and reliable capacitor.

In summary, the Murata GRM155R71H104KE14D capacitor's noteworthy impedance performance truly showcases the component's high engineering standards. Its exceptional consistency, even under varying test conditions, establishes the capacitor as an ideal choice for discerning engineers seeking a dependable and high-performing ceramic X7R capacitor to incorporate into their circuit designs.

Capacitance

The Murata Electronics GRM155R71H104KE14D capacitor is a Ceramic X7R component with a nominal capacitance of 100nF and a ±10% tolerance, proving reasonably competitive within the statistical benchmark for capacitors of identical value. Examining the LCR (Inductance, Capacitance, and Resistance) measurements at 1 Volt and 10 Volts against the benchmark data offers a comprehensive understanding of this component's operational stability and performance when subjected to various test frequencies.

At 1 Volt, the GRM155R71H104KE14D exhibits admirable capacitance values throughout the frequency spectrum. Notably, at lower frequencies (5Hz to 500Hz), the measurements range from 102.1nF at 5Hz to 100.2nF at 500Hz. This range demonstrates stability with a marginal decline, indicating no significant deviances from the nominal capacitance value. In comparison with the average benchmark capacitance, this range shows satisfactory results, particularly as the GRM155R71H104KE14D surpasses the average at 5Hz. Furthermore, as the frequency increases from 500Hz to 1 MHz, the component's capacitance experiences a slight dip. However, it manages to maintain competitive performance against the statistical benchmark.

Regarding LCR measurements at 10 Volts, the GRM155R71H104KE14D demonstrates excellent performance in capacitance values. With minimum capacitance values of approximately 98.53nF at 100kHz and peaking at 108.6nF at the lowest frequency (5Hz), the capacitor promotes superior results within the statistical benchmark. Of particular significance, the higher voltage emphasizes the device's robustness by consistently outperforming the benchmark averages throughout the test.

The GRM155R71H104KE14D continually delivers reliable capacitance values across its operational range. It remains a suitable choice for engineers looking for capacitors within this specific value range. Exceeding various statistical benchmark averages at both voltage settings, the Murata Electronics GRM155R71H104KE14D capacitor demonstrates its merit as an essential component for a vast array of applications. It excels in terms of performance and stability, proving its value to electronics engineers as a reliable and versatile capacitor.

Series Resistance

An in-depth analysis of the series resistance of the GRM155R71H104KE14D ceramic capacitor, manufactured by Murata Electronics, reveals crucial insights into the performance characteristics of this component. When subjected to LCR measurement values at 1 Volt, the capacitor's series resistance values ranged from a high of 5.855k Ohms at 5 kHz to a low of 35.77m Ohms at 1 MHz. A comparison with the statistical benchmark data for capacitors of the same value reveals that the GRM155R71H104KE14D exhibits higher series resistance values in the lower frequency ranges, while showcasing superior performance as the frequency increases.

For example, at 5 kHz, the component's series resistance of 5.855k Ohms is less favorable when compared to the average benchmark value of 8.751k Ohms. However, at 1 MHz, the GRM155R71H104KE14D achieves a series resistance value of 35.77m Ohms, which is a significant improvement compared to the benchmark average of 70.07m Ohms. This noteworthy performance at higher frequencies makes the capacitor an attractive option for engineers to consider when designing circuits operating within that range.

Upon evaluating the LCR measurements taken at 10 Volts, the GRM155R71H104KE14D capacitor exhibited results with a peak series resistance value of 14.95k Ohms at 5 kHz, while the minimum value reached 67.26m Ohms at 650 kHz. In comparison with the benchmark data, it becomes apparent that the GRM155R71H104KE14D continues to present higher series resistance values at lower frequency ranges. Nonetheless, the capacitor exhibits commendable performance when operating at higher frequencies. For instance, at 50 kHz, the capacitor's series resistance is measured at 1.319k Ohms, which is only slightly above the benchmark average.

Due to the marginally higher series resistance values observed at lower frequencies, engineers should exercise caution when incorporating the GRM155R71H104KE14D ceramic capacitor into circuits that require optimal low-frequency performance. However, given the impressive series resistance values demonstrated by the capacitor at elevated frequencies, the GRM155R71H104KE14D capacitor emerges as a compelling choice for engineers in the development of high-frequency circuits.

Dissipation Factor and Quality Factor

The GRM155R71H104KE14D capacitor, a Ceramic (X7R) type, exhibits promising dissipation factor (Df) values when tested at 1 Volt. The Df values range from 0.015 at 100 kHz to 0.020 at 1 MHz, indicating low energy dissipation and reduced ESR, which is generally desirable in electronic circuits. Additionally, this component showcases impressive results in terms of quality factor (Q), which is a measure of the capacitor's efficiency and resonant characteristics. The Q values range from 49.80 at 1 MHz to 67.98 at 150 kHz, representing a decent range of energy-storing capabilities and minimal losses.

Upon examining the capacitor's performance at 10 Volts, the GRM155R71H104KE14D demonstrates higher Df measurements in comparison to the 1 Volt testing, expanding across a range of 0.025 at 600 kHz to 0.051 at 5 Hz. This increase in Df values may result in a more considerable energy dissipation and a slightly increased ESR. Correspondingly, the Quality Factor appears to degenerate slightly as well, with values between 19.47 at 5 Hz to 40.92 at 550 kHz, indicating a decline in the capacitor's performance at elevated voltages.

While comparing the GRM155R71H104KE14D capacitor to the benchmark data, we can observe that it presents a fairly consistent profile across different test frequencies. When operating at 1 Volt, the Df values are promising, and the Q values depict a decent range, making it suitable for applications that prioritize low energy losses and efficient energy storage characteristics. However, an increase in voltage to 10 Volts brings subtle degeneration in both Df and Q values, which might impede the overall performance of this particular capacitor in specific applications. Hence, it is essential to consider the operating voltage and frequency range requirements, along with other crucial parameters such as temperature stability, capacitance change, and interference, while selecting the appropriate capacitor for your design application.

Comparative Analysis

Conclusion

In this technical review, the Murata Electronics GRM155R71H104KE14D capacitor, a surface mount, Ceramic: X7R capacitor with a nominal value of 100n, ±10% tolerance and a 50 voltage rating, was analyzed against a statistical benchmark to thoroughly assess its performance.

The GRM155R71H104KE14D has comparable impedance values to the benchmark data, with the minimum, average, and maximum value differences remaining relatively close. Furthermore, the dissipation factors for the majority of frequencies are within the range of benchmark data, showing consistent performance. Quality factors for the capacitor often fall within the statistical benchmark boundaries, with a few slightly better or worse values depending on the test frequency.

When compared to the statistical benchmark data, the series resistance of the GRM155R71H104KE14D capacitor shows similar trends, closely matching the average benchmark values at the majority of voltages. However, for higher voltages, there is some deviation. The series capacitance values follow a comparable trend with the benchmark's average values, displaying a fairly consistent performance.

Overall, the Murata Electronics GRM155R71H104KE14D capacitor demonstrates a generally reliable performance in its respective category of Ceramic: X7R capacitors. It is well-suited for degreed engineers who are evaluating this capacitor to incorporate into their product designs. While the capacitor may not be the top performer in all aspects, it offers consistent performance across various test frequencies, making it a viable option for diverse applications.
