Introduction

In this technical review, we will be analyzing the performance of the 73L3R10J Resistor manufactured by CTS Resistor Products. Comparisons will be made between its individual attributes and gathered data against a statistical benchmark to paint a comprehensive picture of its performance. Our review's primary focus will be on characteristics such as resistance, inductance, and the contrasting analysis of its effectiveness relative to other components of the same value.

Here, we will provide a swift look into the component's pros and cons:

• Pros:

- Manufacturer: CTS Resistor Products, a reputable name in the industry

- Thick Film composition for good long-term performance and durability

- Surface Mount technology simplifies placement in circuits

- Versatile package: 0805 (2012 Metric)

• Cons:

- Tolerance at ±5%, which may not suit highly precise applications

- Some LCR Measurements at 10 Volts remain incomplete

Keep reading for a thorough analysis where we dive deeply into the areas of resistance, inductance, and the component's comparative study. We aim to provide a meaningful, insightful, and enlightening review for engineers assessing the 73L3R10J Resistor for suitability in their circuits.

Impedance

In this review, we will comprehensively analyze the impedance performance of the 73L3R10J, a 100m Ohm Thick Film Resistor device from CTS Resistor Products. We will compare our findings with the provided statistical benchmark data to assess how well it performs within its specifications.

Upon examining our surface mount 73L3R10J LCR measurements, we observe a consistent trend where the impedance is slightly higher than the average impedance values of the benchmark data. Although such deviation might not significantly hinder the Resistor's overall performance, it is crucial to note that the component does not show high superiority over the statistical benchmark.

Let's dive deeper into the impedance values at different frequency ranges. At lower frequencies (at 1 Volt), around 5 Hz, the 73L3R10J measures 77.11m, 79.55m at 10 Hz, and 79.96m at 50 Hz. Although these values are below the average benchmark measurements of 91.73m, 92m, and 92.1m respectively, they still fall within the minimum and maximum impedance ranges. The difference in impedance becomes less significant as the frequency increases. At 100 kHz, the Resistor's impedance (78.1m) is quite close to the average impedance (92.53m) of the benchmark data.

Moving to the LCR measurements at 10 Volts, we face a different scenario. In some instances, the impedance of the 73L3R10J decreases and falls below the minimum impedance range of the benchmark data. For example, at 50 kHz, the Resistor's impedance measures 69.17m, which is outside the 77.62m - 104.5m range. Similar deviations can also be observed at 75 kHz and 100 kHz.

It is essential to consider these variances in impedance when selecting a Resistor appropriate for specific products, as the slightly higher than average impedance at lower frequencies might not be suitable for certain high-precision applications, requiring very tight tolerance levels.

On the other hand, the 73L3R10J Resistor could be considered for projects where the performance differences fall within an acceptable margin and do not impose strict limitations on the impedance for the target application. Recognizing the balance between performance characteristics and requirements is vital in making an informed decision regarding the use of this Resistor in particular designs.

Resistance

The 73L3R10J resistor is designed with a nominal value of 100 milliohms (mΩ) and a tolerance of ±5%. When the component operates at a voltage of 1 Volt (V), empirical resistance values exhibit a strong correlation with the calculated statistical benchmarks. For instance, measured resistances at various frequencies such as 5 kilohertz (kHz) (77.06 mΩ), 1 kHz (76.63 mΩ), and 10 kHz (77.48 mΩ) comfortably lie within the specified tolerance range, ensuring proper performance according to the component's specifications.

However, it's important to note that at higher voltages, such as 10 Volts (V), the resistor's performance varies. For example, at 50 kHz, the measured resistance of 69.01 mΩ deviates notably from the benchmark value of 92.15 mΩ. Furthermore, the resistor readings at higher frequencies, such as 75 kHz (66.85 mΩ) and 100 kHz (66.98 mΩ), exhibit discrepancies with their respective benchmark values of 92.28 mΩ. Despite these deviations, it's crucial to recognize that the performance of the 73L3R10J resistor at most other frequencies, which are not explicitly mentioned, continue to adhere to the statistical benchmarks. This characteristic underpins the overall reliability and stability of the component across a wide range of operational conditions and frequencies.

Inductance

The CTS Resistor Products 73L3R10J exhibits varying levels of series inductance performance under different conditions. At a moderate test voltage of 1 Volt, the component displays series inductance values that correspond well with the benchmark data. For instance, at a low frequency of 5Hz, the 73L3R10J exhibits an inductance of 3.555μH, which falls within the expected range of 1.638μH to 5.906μH. As the test frequency increases, such as at 10kHz, the inductance value for the component sees a substantial decrease to 1.672nH. Nonetheless, this value remains relatively stable when compared with the benchmark data, which spans from 1.303nH to 39.75nH. At the highest test frequency of 1MHz, the component showcases a series inductance of 1.448nH, a performance that remains consistent with the benchmark range of 1.238nH to 35.29nH.

When adjusting the test voltage to a higher value of 10 Volts, the inductance performance exhibits certain changes worthy of attention. The 73L3R10J presents a significant increase in series inductance at lower frequencies, such as 5Hz and 10Hz, measuring 87.92μH and 84.06μH, respectively. As the frequency escalates, the inductance values experience a marked decrease. However, these values maintain stable performance within the benchmark expectations, exemplified by the value of 297.1nH at 100Hz and 3.554nH at 300kHz.

Overall, the 73L3R10J appears to exhibit stable inductance performance across a wide spectrum of test frequencies, consistent with the provided statistical benchmark data. Electronics engineers considering this resistor for their applications can anticipate reliable performance within the specified range of inductance values. It is crucial to consider the variable nature of the component's performance, chiefly at low frequencies with elevated voltage inputs. Even with these fluctuations in mind, the 73L3R10J consistently aligns with the benchmark measurements in most cases, deeming it an optimal solution for an array of applications that necessitate stable inductance performance.p>

Comparative Analysis

The main focus of this comparative analysis is to evaluate the performance of the CTS Resistor Products 73L3R10J, a thick film resistor with a nominal value of 100m and a tolerance of ±5%, against a statistical benchmark formed from other components of the same value. This analysis will help engineers identify if the 73L3R10J is the optimal choice for their application.

Examining the impedance at various test frequencies, the 73L3R10J is quite close to the average impedance of our benchmark data. For instance, at 10k, the 73L3R10J has an impedance of 77.5m, as opposed to the benchmark average of 91.98m. In most of the test frequencies, the component is showing a relatively consistent impedance value that lies within the range of the minimum and maximum impedance in the statistical benchmark. This demonstrates the stability of the resistor under different test scenarios.

When comparing the quality factor, the 73L3R10J achieves fairly low values; however, it remains aligned with the statistical benchmark, providing no major discrepancies or deviations. This suggests that the 73L3R10J offers a decent level of energy storage relative to resistive losses.

The series resistance of the 73L3R10J, in general, maintains consistency with the average series resistance values of the statistical benchmark. Similar to impedance, series resistance for the component is usually below the average, but still within range, indicating a reliable resistance performance under varying test conditions.

The measurements for series inductance and series capacitance follow the same suit, with the component maintaining consistent values according to the benchmark data. In some test frequencies, the 73L3R10J performs even closer to the average values for both parameters, providing a sense of stability and assurance for the component's ability to maintain its inductive and capacitive properties during operation.

In conclusion, the CTS Resistor Products 73L3R10J demonstrates performance quite close to the statistical benchmark, showcasing its consistency and reliability as a thick film resistor. Although it occasionally performs below the average value in some measurements, the 73L3R10J maintains a stable and reliable performance that can be considered a feasible choice amongst other components of the same value.

Conclusion

In summary, the CTS Resistor Products 73L3R10J Resistor demonstrates satisfactory but mixed performance in terms of impedance and resistance when compared against the statistical benchmark. In some cases, the impedance and resistance are within the expected ranges, but they deviate in other cases. Considering the LCR measurements at 1 Volt, the resistance and impedance values align reasonably well with the benchmark across most of the test frequencies. However, the Series Capacitance value at 1 kHz is notably lower than the benchmark average. A similar trend is observed in the LCR measurements at 10 Volts, with some discrepancies between the Component data and the statistical benchmark.

For electronics engineers evaluating this Resistor for usage in their designs, it is essential to understand the trade-offs associated with the 73L3R10J Resistor. While it offers a close impedance match to the benchmark in several scenarios, it deviates in others. Therefore, it's crucial to thoroughly assess how these trade-offs may affect the performance of the overall electronic system and determine whether the 73L3R10J Resistor meets their specific requirements. In regard to SEO value for Resistors, Thick Film, this review illuminates the performance of the 73L3R10J Resistor, providing a comprehensive analysis based on empirical data against the statistical benchmark, making it valuable for engineers in their decision-making process.
