Introduction

In this comprehensive review, we are evaluating the performance of Bourns Inc.'s CRL0603-JW-R100ELF Resistor. This component is a 100mΩ thick film resistor that comes with a ±5% tolerance and is designed for Surface Mount applications in a 0603 (1608 Metric) package. Our analysis will illustrate this resistor's performance relative to its competitors and the provided statistical benchmark data. Below is a summary of the pros and cons of the CRL0603-JW-R100ELF resistor:

Pros:

• Wide range of LCR measurements spanning from 5Hz to 1MHz
• Stable resistance values within the specified tolerance across the frequency range
• Low dissipation factor and quality factor across multiple test voltages

Cons:

• No available data for Series Capacitance at 10 Volts for most test frequencies
• Some inconsistencies in data collection in the higher frequency range (750kHz to 1MHz) at 10 Volts

The technical analysis in the following sections will delve deeper into the component's resistance, inductance, and a comparative assessment to the statistical benchmark data. Engineers looking to incorporate this resistor in their circuits will find this review beneficial to assess its performance relative to the benchmark data and understand its overall suitability for various applications.

Impedance

The Bourns Inc. CRL0603-JW-R100ELF thick film resistor is known for its exceptional performance when compared to the statistical benchmark data. Featuring a nominal resistance value of 100 milliohms (mΩ) and an allowable tolerance of ±5%, the impedance measurements of this resistor stand as evidence to its high-quality performance. In this review, we will analyze the measurements recorded at both 1 Volt and 10 Volts across various frequency ranges, comprehensively covering the impedance characteristics of this particular resistor.

When subjected to a 1 Volt test voltage, the CRL0603-JW-R100ELF resistor displays impedance values between 94.08mΩ and 94.26mΩ over the entire tested frequency range, spanning from 5 Hz to 1 MHz. Comparison with available benchmark data reveals that the impedance values for the Bourns CRL0603-JW-R100ELF are consistently higher than average values from the benchmark, which range from 91.73mΩ to 108.3mΩ. Of note, the maximum impedance observed at different frequencies in the benchmark data falls between 104.4mΩ and 245.6mΩ, providing valuable context for our analysis.

Moving onto measurements recorded under an input voltage of 10 Volts, we observe considerable variations in impedance values when compared to benchmark data. Across a frequency range of 5 Hz to 20 kHz, impedance values lie between 82.4mΩ and 101.9mΩ, with a tendency towards slightly higher impedance. However, for frequencies exceeding 20 kHz, the CRL0603-JW-R100ELF resistor registers lower impedance values in contrast to the benchmark data. This discrepancy becomes most significant across the 50 kHz to 700 kHz frequency range. Understanding these variations and differences in impedance values at distinct voltage levels and frequency ranges empowers electronics engineers to optimally select and utilize resistors, such as the Bourns CRL0603-JW-R100ELF, within diverse electrical circuits and applications.

Resistance

The Bourns Inc. CRL0603-JW-R100ELF Resistor, a Thick Film type, presents a noteworthy performance in resistance values across the frequency range compared to statistical benchmark data. This component, with a nominal value of 100 milliohms (mΩ) and a tolerance of ±5%, exhibits consistent series resistance values ranging from 94.16mΩ to 94.25mΩ when tested at 1 Volt and a 5 - 400kHz frequency range, showcasing uniformity within this spectrum.

In the 450kHz to 1MHz frequency range, the CRL0603-JW-R100ELF Resistor displays a slight decrease in series resistance values, observed between 93.96mΩ and 93.83mΩ. In comparison, the statistical benchmark's average series resistance data spans from 91.83mΩ to 93.43mΩ for frequencies between 1k to 1M, representing higher variability than the Bourns Inc. resistor.

Upon evaluating the benchmark's maximum and minimum values at 1 Volt, it can be deduced that the CRL0603-JW-R100ELF exhibits a significantly stable performance. Maintaining series resistance values almost in the middle of the statistical benchmark data, this component consistently stays within the acceptable resistance values, without surpassing the maximum or dropping below the minimum values.

It is important to note that the results obtained in tests conducted at 10 Volts deviate further from the benchmark data. However, since the benchmark data only consists of 1 Volt operational values, it is essential to confine our 10 Volts comparisons to the 1 Volt benchmark numbers while acknowledging potential discrepancies. At 10 Volts, the resistor's values observed are higher at lower frequencies (5kHz to 10kHz), but display increased divergence as frequencies extend from 20kHz to 1MHz.

To summarize, the Bourns Inc. CRL0603-JW-R100ELF Resistor demonstrates reliable and consistent performance at 1 Volt within the 5 - 400kHz frequency range, exhibiting values closely aligned with the statistical benchmark's average data under those conditions. At higher frequencies, the resistor's performance falls slightly below the benchmark's average but yet, continues to operate within the tolerable benchmark range, exhibiting its reliable nature.

Inductance

When examining the inductance characteristics of the Bourns Inc. CRL0603-JW-R100ELF Resistor, we compare its performance to a statistical benchmark consisting of similar components. This allows us to better understand its behavior in different scenarios and evaluate its suitability for various applications.

At a test voltage of 1 Volt, the CRL0603-JW-R100ELF Resistor exhibits a low series inductance of 3.039μHenries when tested at a frequency of 5Hz, which comes close to the average inductance value found in the benchmark (3.411μHenries). Further analysis of inductance values at other test frequencies shows that this particular resistor remains within acceptable limits compared to the statistical benchmark.

At a higher test voltage of 10 Volts, the inductance values report mixed outcomes compared to the benchmark. Series inductance measurements at lower test frequencies, such as 5Hz and 10Hz, are significantly higher than the average values observed in the statistical benchmark (89.45μHenries and 85.13μHenries, respectively). However, when tested at a frequency of 100Hz, the inductance value of 327nHenries falls within an acceptable range of the benchmark's average series inductance of 52.5nHenries at the same frequency.

It is important to assess how these varying inductance results may affect the performance of the CRL0603-JW-R100ELF Resistor in specific applications. Engineers should thoroughly evaluate its suitability for their particular requirements, taking into account both its strengths and potential weaknesses when used in certain situations. This allows for a comprehensive understanding of the resistor's capabilities and ensures the optimal component selection for the intended application.

Comparative Analysis

The Bourns Inc. CRL0603-JW-R100ELF thick film surface mount resistor, rated at a nominal value of 100m ohms with a tolerance of ±5%, is the subject of our comparative analysis. We will evaluate its performance against the given statistical benchmark data for resistors of the same value at two different voltage levels: 1 Volt and 10 Volts.

At 1 Volt, the CRL0603-JW-R100ELF demonstrates consistent impedance values across the test frequency range, with a minimum impedance of 94.08m Ohms and a maximum of 94.2m Ohms. In comparison to the benchmark statistics, the Bourns resistor is slightly higher, with a difference of about 1.5% in the impedance figures. Additionally, the series resistance measurements are consistent, hovering near the nominal 100m Ohm value. It's also worth noting that the series inductance values are relatively higher in the 5kHz to 50kHz range compared to the benchmark, while capacitance values exhibit similar performance where data is available.

At 10 Volts, the CRL0603-JW-R100ELF highlights a slightly wider-ranging impedance behavior, with values from 83.25m Ohms to 101.9m Ohms across the test frequency range. The series resistance values remain close to the nominal 100m Ohm value, while the series inductance and capacitance performances continue to demonstrate a relative correlation with the benchmark data. The quality factor measurements at higher frequency ranges are low, but slightly higher than the benchmark, indicating a generally comparable performance.

In conclusion, Bourns Inc.'s CRL0603-JW-R100ELF exhibits a moderately deviated impedance and series resistance performance compared to the benchmark values of the same specification resistors. However, the series inductance values and the exceptional consistency in its readings across the frequency ranges showcase its potential suitability for particular applications. Professional engineers are encouraged to consider this observation in line with their specific design requirements to make an informed decision.

Conclusion

Upon examination of Bourns Inc.'s CRL0603-JW-R100ELF Resistor's performance against the provided statistical benchmark, it is evident that this thick film resistor exhibits several positive aspects but also has room for improvement in select areas. Since this review is aimed at engineers who are interested in assessing the suitability of this particular resistor in their circuits, we will analyze its performance based on impedance, resistance, inductance, and quality factor measurements at 1 Volt and its impedance, dissipation factor, and series resistance at 10 Volts.

When considering the 1 Volt measurements, the CRL0603-JW-R100ELF resistor does a commendable job of maintaining consistent impedance values across most frequencies, particularly 50 kHz to 1 MHz. While outperforming the benchmark in the 100 kHz to 1 MHz range, it slightly lags in the 5 kHz to 50 kHz range. In terms of series resistance, the component demonstrates remarkable steadiness and comparative performance in relation to the benchmark values. However, its quality factor is generally lower to varying degrees across the frequency range when compared to the benchmarks.

On the other hand, at 10 Volts, the CRL0603-JW-R100ELF resistor exhibits comparable impedance performance to the benchmark over several tested frequencies. Most notable is the improved impedance exhibited at 50 kHz. The resistor's series resistance remains consistent and closely mirrors the benchmark values up to frequencies of 100 kHz. Beyond that point, the values tend to diverge to a certain extent. The resistor's dissipation factor, while providing a better result at 5 kHz, progressively increases at higher frequencies, which implies a decrease in efficiency under high voltage operation.

In conclusion, Bourns Inc.'s CRL0603-JW-R100ELF Resistor proves to be a reasonably efficient and stable resistor for applications requiring consistent performance in the 50 kHz to 1 MHz frequency range under 1 Volt operating conditions. However, engineers should exercise caution when considering utilizing this resistor in high voltage applications or circuits where a high quality factor is of utmost importance, as its performance in these areas shows room for improvement when compared to the statistical benchmark. Overall, with a thorough understanding of its strengths and limitations, the CRL0603-JW-R100ELF Resistor can be a suitable and effective component for many circuit deployments.
