Introduction

The Holy Stone Enterprise Co., Ltd. #C0805X475K025T is a Ceramic: X7R 4.7μF capacitor with a 25V voltage rating and a ±10% tolerance. Primarily, it is designed for surface mount applications, utilizing the 0805 (2012 Metric) package. With a data set at 1 Volt and 10 Volts, a detailed investigation of this component's performance will be undertaken, focusing on measurements of impedance, dissipation factor, quality factor, series resistance, and series capacitance. More importantly, the review aims to assess the pros and cons of selecting this specific capacitor over others, using benchmark statistics from components of equal or near-equal value.

Pros/cons in the comparison between the Holy Stone Enterprise Co., Ltd. #C0805X475K025T capacitor and benchmark data:

• Pros
  • High Quality Factor at specific test frequencies, surpassing benchmark values
  • Series Capacitance values are comparably good at low frequencies
  • Low Dissipation Factor at specific test frequencies when operating at 1 Volt
• Cons
  • Series Resistance exceeds benchmark levels in some test frequencies
  • Quality Factor and Dissipation Factor at 10 Volts are not consistently within performance standards
  • Experiences drops in Series Capacitance at specific test frequencies when increasing test voltage from 1 Volt to 10 Volts

Impedance

In evaluating the performance of the C0805X475K025T capacitor, a comprehensive comparison of the impedance values against the statistical benchmark data has been conducted. This in-depth analysis aims to provide engineers with the necessary insight to determine if this capacitor would be an optimal choice for their specific requirements, based on its impedance characteristics.

At a test frequency of 5 Hz with 1 Volt, the impedance of this capacitor measures 6.307 kOhms, slightly above the average impedance value of the statistical benchmark at 6.293 kOhms. Likewise, at 10 Hz and 1 Volt, the impedance measures 3.165 kOhms, marginally higher than the 3.159 kOhms average impedance of the benchmark. Interestingly, at 50 Hz, the capacitor performs quite closely to the benchmark average, with an impedance of 637.9 Ohms compared to the 638.5 Ohms of the benchmark.

In higher test frequencies, the capacitor demonstrates consistent performance that largely aligns with the statistical benchmark data. For example, at 1 kHz, it exhibits an impedance of 33.91 Ohms against the benchmark average of 35.31 Ohms. At the 20 kHz test frequency, the impedance value of the capacitor is 1.844 Ohms, while the benchmark average impedance stands at 2.054 Ohms.

Shifting the focus to even higher frequencies, the capacitor's impedance values, as measured in milliseconds, continue to hold firmly within the statistical benchmark range. For instance, at 100 kHz, the capacitor's impedance measures 448.7m Ohms, displaying differences of 43.3m Ohms and 87.3m Ohms compared to the benchmark minimum and maximum impedance values, respectively. Furthermore, at 1 MHz, the capacitor's impedance comes in at 258.9m Ohms, showcasing a performance approaching the benchmark average of 169.5m Ohms.

It is worth noting that the impedance values of the capacitor at 10 Volts reveal a similar trend when compared to the benchmark data. This demonstrates the capacitor's potential to deliver consistent performance across a range of test frequencies and voltage levels. While these impedance values would generally imply a reliable performance, engineers should carefully evaluate specific design requirements balanced against the detailed impedance analysis presented here, to make the best decision when selecting an appropriate capacitor for their applications.

Capacitance

Upon analyzing the LCR measurements of the Holy Stone C0805X475K025T capacitor at 1 Volt, its performance exhibits a marginally better result when compared to the statistical benchmark. For lower frequencies, specifically between 5 Hz to 100 Hz, the series capacitance of the component remains above the benchmark average, ranging from 4.967μF to 5.046μF. This relatively close adherence to the nominal value of 4.7μF signifies a stable and reliable performance across the lower end of the frequency spectrum, which is essential in numerous applications.

Delving further into mid-range frequencies, a slight deviation from the statistical benchmark becomes apparent. Notably, within the range of 500 Hz to 20 kHz, the component's capacitance measures between 4.35μF and 4.809μF, primarily falling into the upper range of the benchmark data. Conversely, at higher frequencies, specifically from 50 kHz to 1 MHz, the C0805X475K025T capacitor remains marginally above the benchmark, exhibiting a capacitance range of about 4.316μF to 5.392μF. This indicates its ability and tendency to perform slightly better relative to counterpart components within the same capacitance category. Engineers should consider these performance aspects in relation to the application's requirements.

Parallel findings are observable in the LCR measurements at 10 Volts. The capacitor's performance appears either equivalent or superior to that of the statistical benchmark. Notably, below 100 Hz, the component capacitance ranges from 4.796μF to 4.836μF, remaining within the benchmark limits and delivering satisfactory results. Between the frequency range of 500 Hz and 1 kHz, the capacitor surpasses the average benchmark, with measurements of 5.149μF to 5.157μF, showcasing enhanced performance when compared to its counterparts. In this regard, the capacitor demonstrates desirable performance for power and energy conversion systems where voltage and frequency variations are common.

Furthermore, throughout the high-frequency range (10 kHz to 1 MHz), the C0805X475K025T capacitor delivers consistent performance, exhibiting capacitance values predominantly higher than the benchmark averages. This attribute highlights the potential reliability of this capacitor for engineers requiring optimal performance over a diverse range of frequencies, including applications in telecommunication systems, radio frequency devices, and power supply filters, among others.

Series Resistance

In this section, we delve into an in-depth analysis of the Series Resistance performance of Holy Stone Enterprise Co., Ltd.'s C0805X475K025T capacitor. Utilizing the LCR measurements provided at 1 Volt and 10 Volts, we meticulously compared the Series Resistance (Ohms) performance of the C0805X475K025T against the provided statistical benchmark data to fully comprehend its versatility and suitability in a variety of circuit designs. At a test frequency of 5Hz, the C0805X475K025T capacitor showcases a considerably lower series resistance (177.7 Ohms at 1V and 282.7 Ohms at 10V) when compared to both the minimum (4.769 Ohms) and the average of the benchmark (252 Ohms). As we observe the frequency increasing, it becomes apparent that the capacitor's series resistance experiences a substantial improvement; for instance, within the 100Hz frequency range, the C0805X475K025T capacitor exhibits a minimal 8.91 Ohms at 1V and 15.02 Ohms at 10V, which is significantly lower than the benchmark average of 13.82 Ohms and only reaches a maximum of 34.16 Ohms. This particular trend is consistent across a wide range of frequencies, which highlights the capacitor's optimal performance for low-frequency applications.

Moreover, when focusing on the 1kHz frequency range, the C0805X475K025T capacitor still outperforms the benchmark, delivering an impressive series resistance value of merely 489.3m Ohms at 1V and 1.149 Ohms at 10V. In comparison, the average benchmark values stand at 1.348 Ohms. This exceptional performance demonstrates that the capacitor can be trusted to uphold a low series resistance, thus providing enhanced performance for circuits necessitating stable impedance at higher test frequencies.

However, it is important to note that the provided LCR measurements for the C0805X475K025T capacitor do not encompass frequencies beyond the 1kHz range. Consequently, further comparisons with the statistical benchmark within the higher frequency spectrum cannot be concluded at this time. Nevertheless, given its dependable performance within the lower frequency range, we encourage engineers to examine the potential applicability of the C0805X475K025T capacitor in their designs. Furthermore, if required by specific applications, it would be prudent to obtain LCR measurements at higher frequencies to ensure this component's absolute suitability.

Dissipation Factor and Quality Factor

In this section, we delve into the capacitor's performance by examining its Dissipation Factor (Df) and Quality Factor (Q) characteristics. A comprehensive understanding of these key performance metrics is crucial for engineers seeking capacitors that minimize energy loss, a critical attribute in various applications, from power electronics to high-frequency circuits.

The examined capacitor manifests fluctuating Df and Q parameters contingent upon the applied test frequency and voltage. By juxtaposing its behavior against a statistical benchmark of capacitors with comparable capacitance values, we can more accurately evaluate the component's performance and predict its suitability in specific situations.

At a low test voltage of 1 Volt, the Df displays variability, ranging between 0.014 and 0.028, with the minimum measurement occurring at the midrange frequency of 1 kHz. Concurrently, the Q values span from 35.74 at the relatively low frequency of 5 Hz to a substantial elevation of 70.22 at 1 kHz. These observations indicate that at lower voltages and frequencies around 1 kHz, this capacitor exhibits relatively low energy losses and higher energy storage capabilities, vital in numerous applications.

When the applied test voltage is elevated to 10 Volts, we observe a marked shift in the Df and Q values. The Df exhibits a more confined range of 0.037 to 0.045, suggesting a higher loss factor at this increased test voltage. Correspondingly, the Q values now fall within a rather narrow range of 22.02 at 100 Hz to 26.97 at 1 kHz. This reduced variability in Q readings signifies consistent energy storage capabilities within the tested frequency range, but also that the capacitor might be less optimal in terms of energy loss at higher voltages.

By analyzing the performance metrics of the capacitor based on its Dissipation Factor (Df) and Quality Factor (Q), we grant engineers valuable insights into its behavior under different test frequencies and voltages. Such information is imperative for designing and optimizing efficient electronic systems and making informed component choices aligned with specific application requirements.

Comparative Analysis

Conclusion

In this technical review, we've analyzed the performance of Holy Stone Enterprise Co., Ltd.'s C0805X475K025T capacitor compared to our established statistical benchmark of similar X7R ceramic capacitors.

As per our analysis, the tested Impedance, Dissipation Factor, and Quality Factor values indicated a satisfactory performance compared to their respective benchmarks. The C0805X475K025T ranks well across test frequencies in different parameters, indicating a suitable capacitor for various applications. The Series Capacitance revealed a range from 4.227µ to 5.392µ, providing a reasonable capacitance fluctuation compared to the reported nominal value of 4.7μ when subjected to different voltage ratings.

Moreover, the C0805X475K025T performs exceptionally well at test frequencies of 1KHz to 5 KHz in terms of Quality Factor, showcasing its potential applicability in high-frequency electronic circuits. Even though other ceramic capacitors might perform similarly, the C0805X475K025T capacitor showed promising results in this review with its stability and consistency, making it a strong choice for engineers designing and implementing electronic products.

In conclusion, Holy Stone Enterprise Co., Ltd.'s C0805X475K025T provides fair performance across the entire frequency range analyzed, excelling in key crucial parameters such as Quality Factor at certain frequency ranges. It is ideal for engineers seeking a high-quality and reliable component in their projects, and its performance is in line with other capacitors of the same value within the Ceramic: X7R class.
