Murata Electronics 100nF GCM155R71H104KE02D Capacitor: In-Depth Technical Review and Analysis

By Mark Harris Monday, 3 April 2023

Dive into an expert technical review of the Murata Electronics GCM155R71H104KE02D capacitor. We will dissect this 100nF Ceramic X7R capacitor's impedance, capacitance, ESR, and more, providing valuable insights for your next engineering project. Our comparative analysis with other popular capacitors will allow you to make an informed decision on whether this component is right for your application.

Introduction

Our technical review focuses on the Murata Electronics GCM155R71H104KE02D ceramic capacitor with the X7R dielectric. This surface-mount component is housed in the 0402 (1005 Metric) package and has a nominal capacitance of 100nF, a voltage rating of 50V, and a ±10% tolerance. It is essential to analyze the capacitor's performance against the statistical benchmark data to determine if it is the optimal choice.

Performing an expert and detailed analysis of this high-quality capacitor, we will highlight the pros and cons, assess the capacitance and comparative performance, and provide a detailed assessment of its technical features, which include, among others, its LCR measurements at different voltages and test frequencies.

The review sections we will be focusing on:

  • Capacitance
  • Series Resistance
  • Dissipation Factor and Quality Factor
  • Comparative Analysis

Pros

  • Wide range of test frequencies
  • Small package for easy integration
  • Stable X7R dielectric material
  • High-quality Murata Electronics manufacturing

Cons

  • Missing LCR measurements at 10V for higher frequencies
  • Quality factor is slightly lower than benchmark at 1 volt

Impedance

Let us evaluate the impedance performance of the Murata Electronics GCM155R71H104KE02D capacitor by comparing it to the provided statistical benchmark data. This analysis serves as a valuable resource for engineers looking to determine the performance of this capacitor in their circuits.

When examining the GCM155R71H104KE02D alongside the benchmark data at 1 Volt, we observe that its impedance values remain consistent across nearly all frequencies, in line with the average impedance values of the benchmark. For example, at 50 kHz, the impedance of the GCM155R71H104KE02D is recorded as 32.11k, only marginally deviating from the average impedance of 31.67k within the benchmark data. A similar pattern is observed at 100 kHz, where the component's impedance value of 17.38k is slightly lower than the average benchmark impedance at 18.07k. These minuscule deviations suggest that the GCM155R71H104KE02D follows the general trend observed among its counterparts.

Proceeding to analyze the performance of the GCM155R71H104KE02D at 10 Volts reveals a similar pattern. Though the impedance at 50 kHz is measured at 29.9k (marginally lower than the average benchmark impedance of 31.44k), the capacitor remains on par with the statistical benchmark across the majority of frequencies. For instance, the impedance of the GCM155R71H104KE02D at 100 kHz is calculated to be 16.42k, closely approximating the benchmark's average impedance of 16.07k.

By comparing the impedance performance of the Murata Electronics GCM155R71H104KE02D capacitor to the statistical benchmarks at both 1 Volt and 10 Volts, one can deduce that it mirrors the average impedance values across a range of test frequencies. Consequently, engineers can expect this capacitor to demonstrate consistent performance when integrated into their circuits alongside other comparable capacitors.

Capacitance

In this section, we will analyze the capacitance values of the GCM155R71H104KE02D capacitor, manufactured by Murata, by comparing them to the statistical benchmark data for capacitors with the same nominal value and type. This particular capacitor has a nominal capacitance of 100 nF, a tolerance of ±10%, and a voltage rating of 50V.

Upon examination of the component's performance at 1 Volt, we find that the measured series capacitance values closely match the average series capacitance values provided by the statistical benchmark data across all test frequencies. For instance, at 5 kHz, the series capacitance is almost identical, with the component measuring at 99.96 nF and the average benchmark value being 101.8 nF. Similar trends can be observed across other test frequencies, with variations that fall within the acceptable tolerance range of ±10%, confirming the reliability of the component's capacitance.

Similarly, when evaluating the performance of the GCM155R71H104KE02D capacitor at 10 Volts, the measured series capacitance values align fairly closely with their respective statistical benchmarks. It is worth noting that at lower test frequencies, the component demonstrates slightly higher capacitance values compared to the benchmark data. For example, at 10 kHz, the measured value for the component is 105 nF, while the maximum value recorded by the benchmark is 106.4 nF. This deviation, although small, could indicate that the capacitor's capacitance performance may be mildly influenced by the applied voltage and the frequency of operation.

Overall, the GCM155R71H104KE02D capacitor exhibits satisfactory performance when compared against the provided statistical benchmark data. The measured series capacitance values are within the acceptable tolerance, demonstrating that the component maintains stable capacitance across the tested frequency ranges. This stability is crucial for ensuring the reliable operation of electronic circuits and systems in which the capacitor is incorporated, providing consistent filtering, coupling, and energy storage capabilities.

Series Resistance

The GCM155R71H104KE02D exhibits a remarkable Series Resistance performance that outperforms the statistical benchmark's average values across test frequencies ranging from 5 to 600 kHz. For instance, at a test frequency of 5 kHz, the GCM155R71H104KE02D's Series Resistance is measured at 5.885k Ohms, which is significantly lower than the benchmark average of 8.751k Ohms. Similarly, at test frequencies of 50 kHz and 500 kHz, the component's Series Resistance values measure 556.1 Ohms and 61.36 Ohms, respectively—both considerably lower than the benchmark's average values of 865 Ohms and 91.81 Ohms.

When operating at 10 Volts, the GCM155R71H104KE02D continues to demonstrate exceptional Series Resistance levels, showing minimal deviation from the 1 Volt measurements. Test frequencies between 5 kHz and 600 kHz yielded a reduction in Series Resistance when compared to the benchmark. It is crucial to mention, however, that Series Resistance data is not available for test frequencies above 750 kHz with this specific component.

Overall, the GCM155R71H104KE02D showcases noteworthy performance in terms of its Series Resistance across various test frequencies, particularly when juxtaposed against the statistical benchmark data. This characteristic makes it a strong contender for engineers seeking high-performing capacitors for their circuits. Nevertheless, to develop a more comprehensive understanding of its performance at higher test frequencies, further testing and analysis would be necessary.

Dissipation Factor and Quality Factor

In this section, we will be examining the Dissipation Factor (Df) and Quality Factor (Q) performance of the GCM155R71H104KE02D capacitor against the statistical benchmark. The capacitor demonstrates a notably low Dissipation Factor across all test frequencies. With Df values ranging between 0.014 and 0.023, it indicates that very little energy is being lost or dissipated by the component. This low Df signifies efficient operation and minimal energy waste. Concurrently, the Quality Factor reinforces the component's excellent performance, with values ranging from 44.30 to 69.17. This superior performance identifies the GCM155R71H104KE02D capacitor as a high-quality component, suitable for circuits that demand minimal energy loss and maximum efficiency.

Next, we will discuss the LCR measurements at 10 Volts. Under these higher voltage conditions, the observed values for Df still remain comparatively low, ranging from 0.025 to 0.052. This indicates that the GCM155R71H104KE02D capacitor continues performing optimally even at increased voltage levels. The Quality Factor at 10 Volts ranges from 19.09 to 40.47. Although these Q values are lower compared to the 1 Volt test data, they are still noteworthy and suggest that the capacitor maintains reasonable performance across various voltage levels. It is important to note that data for test frequencies between 750 kHz to 1 MHz under 10 Volts is not available, which restricts our analysis for this particular voltage range.

To summarize, the low Dissipation Factor and appreciable Quality Factor exhibited by the GCM155R71H104KE02D capacitor highlights its effectiveness and efficiency for a broad range of applications where energy conservation and performance are critical. These factors should be taken into account by engineers and designers when integrating this capacitor into their electronic circuits and systems.

Comparative Analysis

In this comparative analysis, the performance of Murata Electronics' GCM155R71H104KE02D capacitor is assessed in relation to the statistical benchmark data for components of the same value. The GCM155R71H104KE02D is a ceramic (X7R) capacitor with a nominal value of 100nF and a tolerance of ±10%.

At the 1V test level, the GCM155R71H104KE02D capacitor displays similar impedance values compared to the average impedance of the benchmark at most test frequencies. For example, at 10 kHz, the capacitor presents an impedance of 159.7 kΩ while the average impedance of the benchmark is 157.2 kΩ. The capacitor's performance remains consistently close or on par with the benchmark at higher test frequencies, such as 100 kHz, 500 kHz, and up to 1 MHz. At the 1 MHz test frequency and 1V test level, the GCM155R71H104KE02D capacitor has a recorded impedance value of 1.797 kΩ, while the benchmark's average impedance value is 1.958 kΩ.

The GCM155R71H104KE02D capacitor also exhibits a comparable dissipation factor relative to the benchmark. At the 1V test level and 10 kHz test frequency, the capacitor presents a dissipation factor of 0.018, while the benchmark's average dissipation factor is 0.03.

Additionally, the GCM155R71H104KE02D capacitor demonstrates similar series resistance values compared to the average series resistance values of the benchmark across test frequencies. For instance, at 50 kHz and 1V test level, the capacitor has a series resistance value of 556.1 Ω, and the benchmark's average series resistance value is 865 Ω. This trend continues at higher test frequencies, such as 100 kHz, 500 kHz, and up to 1 MHz.

In summary, the Murata Electronics GCM155R71H104KE02D capacitor performs consistently close or on par with the statistical benchmark data for components of the same value across various test frequencies and voltage levels, making it a suitable choice for engineers seeking a ceramic (X7R) capacitor for their applications.

Conclusion

In conclusion, the Murata Electronics GCM155R71H104KE02D is a Ceramic: X7R capacitor with a decent performance against the statistical benchmark. This capacitor, with a nominal value of 100n and a ±10% tolerance, provides reliable performance in a variety of electronic applications.

At 1 Volt, the GCM155R71H104KE02D capacitor maintains a consistent impedance, quality factor, and series capacitance across most test frequencies. The average dissipation factor stays within the 0.01 to 0.03 range for test frequencies up to 1MHz. Notably, at 10 Volts, the capacitor performs well with respect to the benchmark data. The impedance, quality factor, and series capacitance remain stable up to 700kHz.

However, it's essential to note that the capacitor's performance starts to deteriorate with increasing frequency. This factor should be taken into consideration when evaluating this capacitor for high-frequency applications.

Overall, the GCM155R71H104KE02D capacitor exhibits satisfactory performance in comparison to the benchmark. For design engineers looking for a reliable Ceramic: X7R capacitor, this component can be considered a suitable choice.
