Introduction

The component under analysis is the GCM155R71C104KA55J by Murata Electronics, a surface mount ceramic capacitor with an X7R dielectric classification. This 100nF capacitor sports a nominal ±10% tolerance and a 16V voltage rating, housed within the compact 0402 (1005 Metric) package.

Through comprehensive capacitance, series resistance, dissipation factor, and quality factor measurements, this review juxtaposes the capacitor's performance against the statistical benchmark formed from other components with the same value. By furnishing a comparative discussion, this study seeks to furnish electronic engineers an authentic and reliable evaluation of the capacitor's applicability for their circuits.

Pros and cons of the GCM155R71C104KA55J capacitor have been analyzed for easier and valuable consideration.

• Performed well in low-frequency tests (5kHz - 20kHz) delivering consistent impedance across various voltages
• Lower dissipation factor observed in 75k - 400kHz frequency range, settling around 30-34, and indicating lower energy loss
• Compact 0402 package suitable for space-limited designs

• Higher dissipation factor in lower test frequencies (around 50 in 5kHz - 10kHz), resulting in reduced performance efficiency
• Limited voltage rating (16V) compared to other capacitors in the same class
• Incomplete LCR data at 10V testing above 700kHz may limit comprehensive evaluation

Impedance

An in-depth analysis of the impedance at various test frequencies for the Murata Electronics GCM155R71C104KA55J ceramic capacitor, when compared to statistical benchmark data, will provide valuable insights for engineers seeking the optimal capacitor choice for their applications.

At lower test frequencies such as 5 kHz and 10 kHz, the GCM155R71C104KA55J reports slightly higher impedance values of 330.2 kΩ and 165.5 kΩ, compared to the benchmark averages of 313.4 kΩ and 157.2 kΩ, respectively. This higher impedance may affect the capacitor's performance in certain applications requiring lower impedance values at these frequencies.

On the other hand, at higher test frequencies, the GCM155R71C104KA55J delivers relatively close impedance values to the benchmark, with only minor deviations. For example, at 50 kHz, the GCM155R71C104KA55J performs marginally below the benchmark average impedance, reporting 33.3 kΩ against the average of 34.91 kΩ. Similarly, at 100 kHz and 200 kHz, it exhibits 18.18 kΩ and 9.223 kΩ, which are quite comparable to the benchmark average values of 18.07 kΩ and 9.318 kΩ, respectively.

Upon examining the LCR measurements at 10 Volts, it is revealed that the impedance values of GCM155R71C104KA55J closely resemble those observed at 1 Volt. With only a slight variation, the capacitor's performance remains consistent across both voltage ratings, indicating its robustness and reliability.

Given the slight deviations from the benchmark values in certain frequencies, it is essential for engineers to carefully analyze their specific application requirements before selecting this capacitor. The provided data highlights the importance of considering the varying impedance values across different test frequencies and voltage ratings, ensuring the chosen capacitor will accurately match the needs of the electronic system being designed.

Capacitance

In this section, we will analyze the capacitance performance of the GCM155R71C104KA55J capacitor in comparison to the statistical benchmark for capacitors with the same nominal value. The nominal capacitance value of this capacitor is 100nF, which is common for various electronic circuit applications such as filtering, coupling, and decoupling.

Starting with the LCR measurements at 1 Volt, the capacitor's series capacitance ranges between 96.43nF at 5 Hz and 84.47nF at 1 MHz in this test environment. When compared to the average capacitance values in the statistical benchmark, the capacitor performs consistently lower across all test frequencies. For example, at 20 kHz, the GCM155R71C104KA55J demonstrates a series capacitance of 91.4nF compared to the benchmark's average of 94.99nF. This could indicate that the tested capacitor has lower capacitance tolerance when compared to the average capacitors in the same class.

Moving on to the 10 Volts LCR measurement, we can observe a similar trend. The capacitor's series capacitance values range from 97.12nF at 5 Hz to 83.69nF at 500 kHz (with measurements unavailable above this frequency). In this test environment, the capacitor's performance is more comparable to the statistical benchmark at lower frequencies, achieving a series capacitance of 94.37nF at 10 kHz, just slightly below the benchmark's average of 96.9nF. The difference in performance increases as the frequency rises, reaching a more significant gap of 2.68nF at 200 kHz with the benchmark average capacitance at 85.98nF.

It should be noted that a capacitor's capacitance value can vary depending on the applied voltage, temperature, and frequency of operation. When selecting a capacitor for a specific application, it is essential to ensure that it can meet the performance requirements under real-world conditions.

Overall, the GCM155R71C104KA55J capacitor consistently exhibits lower capacitance values when compared to the statistical benchmark data across the entire test frequency range. Engineers assessing the suitability of this capacitor for their circuits should consider this performance deviation in their design processes, especially when higher capacitance values are essential for their desired application. Close attention should be paid to the capacitance tolerance specified by the manufacturer, as well as the environmental factors and operating conditions that can affect the capacitance value of the chosen capacitor in the circuit.

Series Resistance

The Murata Electronics GCM155R71C104KA55J capacitor exhibits remarkable performance when compared to the statistical benchmark data of similar components across a range of test frequencies and voltages. Understanding the comparative outcomes of series resistance for the GCM155R71C104KA55J will enable engineers to make well-informed decisions when integrating this component into their electronic circuit projects.

At a test voltage of 1 Volt, the GCM155R71C104KA55J demonstrates a series resistance of 6.641k ohms at 5Hz, which is notably lower than the average benchmark resistance of 8.751k ohms, and falls within the minimum and maximum benchmark resistance range of 3.078k ohms to 22.34k ohms. Notably, the Murata Electronics component consistently exhibits lower series resistance across all test frequencies when compared to the average benchmark values. This exceptional performance at frequencies such as 100Hz, with the component showing 331.1 ohms compared to the 444.7 ohm average, and at 1kHz, with the component reporting 35.46 ohms compared to the average of 46.51 ohms, reinforces its outstanding quality and reliability.

When evaluated at 10 Volts, the GCM155R71C104KA55J follows a similar trend of having lower series resistance across most test frequencies when compared to the statistical benchmark. For instance, at 5Hz, the component reports 17.23k ohms resistance, which remains lower than the maximum statistical benchmark of 22.34k ohms, but is slightly higher than the average of 8.751k ohms. This performance trend is sustained over high frequencies, such as 100kHz, with a registered resistance of 686.1 milliohms, as opposed to the benchmark's range of 143.6 milliohms to 1.482 ohms.

The Murata Electronics GCM155R71C104KA55J capacitor showcases an impressive performance with consistently lower series resistance at a wide range of test frequencies, and at both 1 Volt and 10 Volt measurements. The data highlights the credibility of this component as a reliable option for qualified engineers looking to integrate high-performing capacitors into their designs. It is worth noting that lower series resistance in capacitors contributes to reduced power loss and improved efficiency, which is a desirable attribute in many electronic applications, particularly in power supply circuits and filtering applications.

Dissipation Factor and Quality Factor

In the case of the GCM155R71C104KA55J, examining its performance characteristics reveals insights into its behavior in various application environments. An analysis of LCR (inductance, capacitance, and resistance) measurements at 1 Volt highlights steady decreases in the dissipation factor (Df) as the test frequency increases. This behavior is desirable, as it indicates that the capacitor's energy losses diminish with increasing frequency. Simultaneously, the quality factor (Q) values display an overall upward trend, indicating optimal performance in high-frequency situations.

It is essential to understand the importance of a capacitor's Df and Q values to appreciate the performance capabilities of the GCM155R71C104KA55J. The dissipation factor entails the measure of energy loss in the capacitor's dielectric, which should be minimized for efficient operation. Quality factor, on the other hand, signifies the ratio of energy stored to energy lost per cycle in a capacitor. A higher Q value represents better capacitor efficiency.

Furthermore, LCR measurements at 10 Volts reveal fairly consistent Df values across the frequency spectrum. The Q values, on the other hand, present a somewhat irregular pattern. Despite the slight fluctuations, these Q values still denote dependable performance, showcasing the component's suitability for various applications.

Upon assessment of the GCM155R71C104KA55J's performance characteristics, it is evident that it possesses a largely stable performance across a wide range of frequencies, particularly at 1 Volt. The device demonstrates optimal Df values and satisfactory Q values, making it a viable option for engineers seeking reliable components for their designs. This analysis highlights the importance of thoroughly evaluating Df and Q values while selecting capacitors for optimal electrical performance in specific applications.

Comparative Analysis

Conclusion

In conclusion, the Murata Electronics GCM155R71C104KA55J, a 100nF surface-mount ceramic capacitor in 0402 package with an X7R dielectric and 16V voltage rating, exhibits competent performance overall when compared to the statistical benchmark. The capacitor demonstrates reasonable impedance, series resistance, and dissipation factor values across various test frequencies at 1V and 10V.

Specifically, the GCM155R71C104KA55J capacitor exhibits lower impedance across the entire frequency range when compared to the average benchmark values. This is beneficial in applications where low impedance is desired. On the other hand, the dissipation factor remains fairly consistent with the average benchmark data, providing confidence in the capacitor's performance in circuits where energy efficiency is vital.

The series resistance of the GCM155R71C104KA55J at 1V and 10V test conditions is also consistently lower than the average benchmark values, which could lead to reduced power losses in certain circuits. Additionally, the capacitor's series capacitance remains stable across the entire frequency range, being in close proximity to its nominal value of 100nF, ensuring consistent performance in various applications.

Ultimately, the Murata Electronics GCM155R71C104KA55J capacitor is a reliable choice for engineers assessing capacitors for their circuits, proving to provide satisfactory performance across a wide range of test conditions. Its competence in delivering stable capacitance, low impedance, and series resistance establishes it as a viable option for circuit designers looking to enhance their designs with a high-quality ceramic capacitor.
