Introduction

The Würth Elektronik 74406043047 is a Drum Core, Wirewound Inductor, that is being evaluated against a statistical benchmark with peers of the same nominal value. Designed for Surface Mount applications, this inductor offers a flexibility of ±30% tolerance on its nominal value of 4.7μH. Boasting a nonstandard package and a current rating of 2.3A, the component will be evaluated based on its LCR measurements at 1V and 10V to determine how it stands up against the competition.

• Pros:
  • Drum Core, Wirewound Inductor design
  • 4.7μH nominal value with a ±30% tolerance
  • Surface Mount compatible
  • Nonstandard package offers additional variation in application
• Cons:
  • LCR measurements across test frequencies paint a varied picture
  • Sometimes modest Quality Factor results
  • Variable performance compared to peers and statistical benchmark

Impedance

This section examines the impedance performance of the Würth Elektronik 74406043047 drum core, wirewound inductor, focusing on its impedance measurements obtained at 1 Volt and comparing them to statistical benchmark data for other components with the same nominal value (4.7μH).

At low test frequencies, such as 5 Hz and 10 Hz, the Würth Elektronik inductor's impedance values appear to align with the benchmark maximum impedance readings (1.774 Ohms and 2.962 Ohms, respectively). As the test frequencies increase, the component's impedance values continue to rise, eventually matching or even exceeding the benchmark maximums. Between 50 kHz and 1 MHz, the measured impedance consistently surpasses the benchmark set maximum impedance.

In the intermediate frequency range of 100 Hz to 1 kHz, the 74406043047 inductor outperforms the benchmark set average impedance, demonstrating its potential for effective operation within specific frequency bands. At a test frequency of 10 kHz, the component's impedance of 3.164 Ohms is both reasonable and persuasive, falling between the benchmark average and maximum values (3.148 Ohms and 3.164 Ohms, respectively).

When subjected to a higher voltage of 10 Volts, the Würth Elektronik inductor continues to perform well at lower test frequencies, such as 5 Hz, 10 Hz, and 50 Hz, exhibiting impedance values of approximately 1.051 Ohms, 1.046 Ohms, and 1.045 Ohms. Yet, as the test frequency reaches 1 MHz, the inductor's impedance surpasses even the highest benchmark value, yielding a reading of 36.61 Ohms as opposed to the benchmark maximum of 32.63 Ohms.

Overall, the Würth Elektronik 74406043047 inductor exhibits a dynamic impedance profile relative to the statistical benchmarks. Engineers must carefully assess the component's impedance performance within the desired frequency range and consider potential high-frequency application scenarios, as the inductor's performance may fluctuate significantly depending on the specific context.

Inductance

Examining the statistical benchmark data, the average inductance at 1V across various frequencies ranges from 4.498μH at 1MHz to 15.29μH at 5Hz. Similarly, at 10 Volts, the average inductance performance of the corresponding benchmark data ranges from 5.796μH at 1MHz to 100.6μH at 5Hz. It is essential to analyze the inductance performance of the Würth Elektronik 74406043047 across the voltage range of 1V and 10V against this benchmark in order to thoroughly understand the component's potential applications.

At 1V, the 74406043047 demonstrates a significantly higher inductance at low frequencies, starting at 76.44μH at 5Hz, which not only exceeds the maximum benchmark value at this frequency but also makes a substantial difference. This trend continues as the inductance reaches 33.4μH at 10Hz. However, the outperformance steadily decreases as the frequency increases, eventually crossing over to below average at 100Hz with 5.385μH, compared to the average benchmark value of 4.94μH at the same frequency. In the frequency range of 500Hz to 1MHz, the 74406043047's inductance remains relatively consistent with the maximum values of the benchmark data, although slightly higher.

When evaluating the inductance performance of the Würth Elektronik 74406043047 at 10V, similar trends emerge as those observed with the 1V analysis. The component demonstrates remarkable outperformance at lower frequencies like 5Hz (100.6μH) and 10Hz (84.62μH). However, there is a noteworthy decrease in inductance at 100Hz (2.16μH) compared to the average benchmark value of 4.93999μH. Beyond that, in the frequency range from 500Hz to 1MHz, the 74406043047 Inductor manages to maintain inductance values between the minimum and maximum benchmark values, ensuring satisfactory performance across a broad spectrum of frequencies.

The Würth Elektronik 74406043047 Inductor exhibits a distinctive inductance performance profile compared to the statistical benchmarks. It surpasses the benchmark at low frequencies, but the inductor's values fall below the average at 100Hz for both 1V and 10V configurations. For frequencies above 500Hz, its performance falls within the benchmark range, providing electronics engineers with the confidence that this inductor will function aptly within those frequency ranges. Considering its unique performance characteristics, the 74406043047 Inductor is an excellent choice for designs requiring higher inductance values at low frequencies while maintaining acceptable performance at higher frequencies within the context of the statistical benchmark data.

Series Resistance

The series resistance of the Würth Elektronik 74406043047 inductor falls within the maximum range as per the statistical benchmark across different test frequencies when operating at 1 Volt and 10 Volts. Series resistance is an important parameter to consider, as it directly affects the efficiency of the inductor and its ability to perform optimally in various applications.

At 1 Volt, the series resistance for the 74406043047 inductor ranges between 1.858 Ohms (at 5Hz) and 7.266 Ohms (at 1MHz). These values showcase the component's competence and reliability under varying frequency conditions. The inductor's performance remains within the maximum series resistance values stipulated by the statistical benchmark, making it an excellent candidate for use in diverse applications.

When operating at 10 Volts, the LCR measurements demonstrate that the 74406043047 inductor also performs well within the statistical benchmark range, with series resistance values extending from 1.051 Ohms (at 5Hz) to 3.738 Ohms (at 1MHz). With these consistent results, the inductor solidifies its position as a strong contender when compared to other similar components, by staying within the acceptable boundaries established by the statistical benchmark dataset.

In summary, engineers assessing the Würth Elektronik 74406043047 inductor for use in their circuit designs can have confidence that the component's series resistance remains on par with the statistical benchmarks during operation at different test frequencies and voltage levels. This characteristic contributes to the inductor's overall reliability and suitability for a wide range of applications, making it a valuable addition to any electronic design project.

Dissipation Factor and Quality Factor

When examining the performance of Würth Elektronik's 74406043047 Inductor, it is crucial to scrutinize its Dissipation Factor (Df) and Quality Factor (Q) at various test frequencies. The Drum Core, Wirewound composition contributes to its overall performance relative to inductors with the same nominal value. These factors indicate energy loss (Df) and the capability of the device to store energy (Q) in reactive power applications, such as filters, oscillators, and transformers.

Taking into account the 1-Volt LCR measurements, the Quality Factor gradually increases as the test frequency advances from 1 kHz (Q = 0.01) up to 1 MHz (Q = 4.38). It suggests that the inductor has better energy storage efficiency at higher frequencies. Similarly, if we assess the 10-Volt LCR measurements, the Quality Factor also escalates rapidly over the test frequency range, starting at 1 kHz (Q = 0.02) and reaching 9.74 at 1 MHz. In both the 1-Volt and 10-Volt scenarios, the progressively increasing Quality Factor supports a favorable performance assessment.

However, to make a comprehensive assessment for the inductor's dissipation factor and quality factor, it is essential to compare the data with benchmark values of similar inductors having a 4.7µH nominal value. Since the Inductor's Df is not explicitly provided for the 74406043047 model, there is a need to procure additional material to obtain a more comprehensive understanding of its performance. Comparing the obtained values with industry standards or manufacturers' specifications will offer better insight into whether the Würth Elektronik 74406043047 Inductor is an optimal choice for the target application or if there are more suitable alternatives available.

Comparative Analysis

The Würth Elektronik 74406043047 Inductor is a Drum Core, Wirewound component featuring a nominal value of 4.7μ, a tolerance of ±30%, a current rating of 2.3A, and a surface mount package. In this comparative analysis, we will assess the performance of this inductor against the provided statistical benchmark data for components of the same value.

At lower test frequencies (5Hz - 1kHz) and 1V, the 74406043047 Inductor's impedance generally stays within the maximum benchmark range. However, as the test frequency increases, we observe that the Inductor's impedance surpasses the maximum benchmark values consistently, reaching 4.38 times the maximum benchmark impedance at 1MHz, which may have several implications depending on the application.

In terms of Quality Factor, the 74406043047 Inductor performs below the benchmark average, only surpassing minimum benchmark values at test frequencies above 1kHz at 1V. While the Inductor's average performance relatively improves at a 10V test condition, it still remains below the benchmark average; this could be a concern for applications in which an Inductor's power factor plays a vital role.

When examining Series Resistance, the Inductor generally stays within the maximum benchmark range when tested at 1V. It is important to mention that it underperforms the minimum benchmark values at frequencies below 500Hz. At a test voltage of 10V, the 74406043047 Inductor approaches closer to the minimum benchmark range, indicating a better performance at a higher test voltage.

Regarding Series Inductance, the 74406043047 Inductor outperforms the statistical benchmark at low frequencies, showing higher inductance values. However, as the test frequency increases, the Inductor's inductance values get more in line with the benchmark averages. The Inductor maintains a close overlap with the maximum benchmark values at frequencies above 100kHz at 1V, whereas it aligns closing to the minimum benchmark values when tested at 10V.

In summary, the performance of the Würth Elektronik 74406043047 Inductor varies and is highly dependent on the frequency and voltage. This Inductor may perform better compared to the benchmark at lower frequencies and higher voltages. The observed differences in performance might have implications in applications where specific aspects such as impedance, quality factor, series resistance, or inductance are a priority. It is crucial to consider these factors and how the Inductor's diverse performance can impact your design before deciding to use it in your project.

Conclusion

In conclusion, the Würth Elektronik's 74406043047 Inductor possesses several notable characteristics when compared to the given statistical benchmark data. At lower test frequencies, this Drum Core, Wirewound inductor outperforms the benchmark with higher impedance & series inductance, and lower series resistance. At higher frequencies, the comparison with benchmark data turns relatively less favorable with 74406043047's impedance values being lower than the benchmark's average, along with a decrease in the Quality Factor.

Moreover, the component performs particularly well in the 1K to 20K test frequency range, boasting a higher Quality Factor than its counterparts in the benchmark datasheet. However, engineers should be aware that improvements start to taper off at frequencies above 20K, with the Quality Factor eventually becoming lower than the benchmark's average.

With a composition of Drum Core, Wirewound, and a Surface Mount package, the Würth Elektronik 74406043047 Inductor exhibits an overall satisfactory performance compared to the statistical benchmark, especially at lower test frequencies. This inductor makes a viable option for engineers who require high-quality low-frequency performance but can tolerate a less impressive performance at higher frequencies.
